Unilin Utherm Roof Pir L 10CM 120/60 - RW 4,50 3.60m²/pak

Utherm Roof L from Unilin is a PIR insulation board with a covering consisting of a gas-tight multi-layer complex of kraft paper and metal foils (aluminum color) on both sides. The board has a straight edge on 4 sides for easy work at edges and corners.

Delivery time: 3-7 working days

TRIPEL PALLET (108.00 M2) = €11.90 / M2 = €1285.20	x	TRIPEL PALLET
PAK (3.60 M2) = €12.75 / M2 = €45.90	x	PAK

Afhalen in Wetteren

Product description
Product specification
Technical sheet

Additional information about the Pir plate L

PIR insulation board coated on both sides with a multi-layer, gas-tight laminate
Declared lambda value : 0.022 W/m.K
L-cladding : multilayer gas-tight laminate
Dimensions : standard 1200 x 600 mm
Edge finish : straight on the 4 sides or with tooth and groove on the 4 sides
obtainable under certain conditions
Suitable for bonded roof structure with a maximum wind load of up to 4000 Pa
Suitable for single, bonded roofing membrane systems thanks to the flat sheet finish
Less deformation during roof installation and maintenance thanks to increased compressive resistance

Attribute name	Attribute value
lenght	120 cm
width	60 cm
thick	10 cm
R value	3.60
lambda value	0.022
Platen per pak	5

Product description

Additional information about the Pir plate L

PIR insulation board coated on both sides with a multi-layer, gas-tight laminate
Declared lambda value : 0.022 W/m.K
L-cladding : multilayer gas-tight laminate
Dimensions : standard 1200 x 600 mm
Edge finish : straight on the 4 sides or with tooth and groove on the 4 sides
obtainable under certain conditions
Suitable for bonded roof structure with a maximum wind load of up to 4000 Pa
Suitable for single, bonded roofing membrane systems thanks to the flat sheet finish
Less deformation during roof installation and maintenance thanks to increased compressive resistance
